San Francisco Series - 4-Arm Cluster Pendant

Click on a finish sample below to change fixture color:

Model Number	Lamping Code	Body Lamping	Circuit	Finish	Diffuser	Mounting	Options	IES	PDF	BIM
SF5012V Dimensions: • W 78" • HT 14" • OAH 36" (OverAll Height) • Y 4 @ 30"x10"	EBW	31,000lm LED (213W)	1	PC	WA PA	STB STC STD STE	D1

	EBX	49,000lm LED (346W)	1	PC	WA PA	STB STC STD STE	D1

	BGD	16-100W A21 (1600W)	1	PC	WA PA	STB STC STD STE

SF6214V Dimensions: • W 96" • HT 16" • OAH 48" (OverAll Height) • Y 4 @ 36"x12"	ECA	37,000lm LED (235W)	1	PC	WA PA	STB STC STD STE	D1

	DWY	54,600lm LED (391W)	1	PC	WA PA	STB STC STD STE	D1

	BGH	24-100W A21 (2400W)	1	PC	WA PA	STB STC STD STE

SAMPLE CATALOG NUMBER

Model Number - Lamping Code - Finish - Mounting - Diffuser - Options

PRODUCT FEATURES

Fabricated and welded metal housing
Powder coated metallic finish
UV stable, white acrylic bowl diffuser (Standard)
Optional specialty diffuser materials available
Energy efficient LED lamping
High power factor electronic LED driver
Wired for dual circuit operation, Body Lamping and Down Lamping
Standard LED CCT is 3000 Kelvin - contact us for alternate color temperature availability
Standard LED CRI is 80 - contact us for alternate CRI availability
Incandescent lamping is Triac or ELV dimmable - consult lamp and dimmer manufacturer for compatibility.
Standard LED dimming is 0-10v
Optional line voltage (Triac or ELV) LED dimming is available - consult for compatibility
Fixture is Chain or Stem hung (extra length may be added, specify OAH) (OAH - Over All Height - is the length from the ceiling to the bottom of the fixture.)
Mounts to standard electrical junction box (by others), Box requires additional structural support (by others)
For slopes greater than 35 degrees (from horizontal) order steep pitch adapter (Stem only)
UL / cUL or ETL / cETL listed
Contact Us for more lamping options.
